⚙️ Shelly Qubino Wave Shutter - Professional Z-Wave Roller Shutter Controller

Shelly Qubino devices operate on the latest generation of Z-Wave 800 Series (S800) chips, one of the most popular and secure standardized smart home technologies globally. With a centralized smart hub (Z-Wave gateway), these products can communicate with one another regardless of their brand or underlying platform.

The Qubino Wave Shutter module is designed for flush mounting directly inside a wall box behind any mechanical switch or button, instantly transforming it into a smart device. After installation, simply pair it to your Z-Wave network and control your connected blinds, shutters, or awnings from anywhere using your smartphone, tablet, or voice assistant. Shelly Qubino devices are interoperable with over 4,000 certified Z-Wave products.

Functions of the Shelly Qubino Wave Shutter Controller

The Wave Shutter connects to your Z-Wave network for reliable remote motor control. It is fully compatible with all certified Z-Wave gateways. Moreover, the Wave Shutter can establish direct communication (associations) with other Z-Wave devices in your local network to execute custom actions without needing a response from the central hub. The module provides highly precise energy consumption monitoring. It allows you to control blind and shutter motors, including specific tilting of external venetian blind slats exactly as you need.

Broad System Compatibility

• ⚙️ Home Assistant (via Z-Wave JS)
• ⚙️ Home Center 3 (Fibaro)
• ⚙️ Jeedom
• ⚙️ Homey
• ⚙️ SmartThings (Aeotec)
• ⚙️ Hubitat

Key Features

• 🔄 Position Control: Precise adjustment of the shutter's overall position and accurate tilting angle for venetian blinds.
• 🔗 Versatility: Supports both connected traditional rocker switches and momentary push buttons.
• ⚡️ Energy Measurement: Built-in wattmeter for both channels reporting real-time data to your central hub.
• 📶 Z-Wave 800 Protocol: The latest generation of communication for outstanding range and responsiveness. Extremely low standby power consumption (<0.3 W).
• 🚀 SmartStart Installation: Quick and secure addition of the device to the network by scanning the PIN/QR code.
• 🔒 S2 Authentication: The highest level of wireless communication security against hackers.
• 🔄 OTA Updates: Supports over-the-air firmware updates to ensure your device is always up to date.

Technical Specifications

• 🔌 Power Supply: 110 – 240 V AC (50/60 Hz)
• ⚡️ Standby Energy Consumption: < 0.3 W
• 💡 Power Measurement [W]: Yes
• 🔌 Maximum AC Switching Voltage: 240 V
• 🔌 Maximum AC Switching Current: 10 A per channel
• 🔥 Overheat and Overload Protection: Yes
• 📶 Distance (Range): up to 40 m indoors (depending on local obstacles and building materials)
• 🔄 Z-Wave Repeater: Yes
• 💻 Processor: Z-Wave® S800
• 📶 Z-Wave® Frequency Band: 868.4 MHz (Europe)
• 📡 Max RF Transmit Power: < 25 mW
• 📏 Dimensions (H x W x D): 37 x 42 x 16 mm (ideal for flush mounting)
• ⚖️ Weight: 29 g
• 🔩 Max Torque for Screw Terminals: 0.4 Nm
• 🔌 Wire Cross-Section: 0.5 to 1.5 mm²
• 🌡️ Ambient Temperature: -20 °C to 40 °C
