Product detailed description

✨ Discreet smart module for the perfect atmosphere

Nice RGBW-Control is a universal controller compatible with Z-Wave Plus™ technology, designed for RGB and RGBW LED strips, halogen lighting, and other resistive loads. Through the app, it offers precise adjustments of light color and temperature, allowing you to create various atmospheres – from cozy warm tones to deep shades of cosmic blue. The device supports various sensors and switches, measures energy consumption, and provides preset lighting scenes inspired by nature. It is ideal for bringing any space to life with dynamic lighting effects and for seamless integration into a smart home.

The module provides simple lighting control and color changes via the Yubii Home app or voice commands. It can manage up to four 0–10 V analog sensors (temperature, humidity, wind, air quality, radiation, etc.). Additionally, the lighting color in your home can be changed based on the weather or time of day.

The 244 Hz PWM signal ensures smooth, flicker-free dimming of light intensity on each of the four independent channels.

This device can be used with all Z-Wave Plus certified devices and should be compatible with devices of this type from other manufacturers. All non-battery-operated devices within the network will act as repeaters, increasing the reliability of the entire network. The device is a Security Enabled Z-Wave Plus product and a Security Enabled Z-Wave Controller must be used in order to fully utilize the product. The device supports Z-Wave network security modes: S0 with AES-128 encryption and S2 Authenticated with PRNG-based encryption.

Main features

🌈 Comprehensive color control

Four independent PWM outputs allow you to separately control each channel (R, G, B, and W) of an RGBW strip, or manage four independent single-color strips. By default, the device operates in RGBW mode, but via Z-Wave parameters, it can be switched to HSB (Hue, Saturation, Brightness) mode, providing a flexible color model choice depending on your current needs. Pre-programmed nature-inspired lighting scenes are also available, allowing you to create the desired atmosphere without manual programming.

🔗 Universal inputs for switches and sensors

Four inputs allow the connection of both momentary and toggle switches, as well as 0-10 V analog sensors with a configurable pull-up resistor. This makes it possible to physically connect existing wall controllers to the module without requiring a Z-Wave connection, and to use environmental sensors to trigger context-aware lighting automation.

📊 Integrated energy monitoring

The module measures the active power consumed by the load in real-time and records the total energy consumed. This data is sent to the Z-Wave controller, enabling long-term lighting consumption tracking and the identification of any anomalies.

📡  Advanced Z-Wave integration

The RGBW-Control module is compatible with any certified Z-Wave or Z-Wave Plus controller. It supports Z-Wave security modes S0 (AES-128 encryption) and S2 Authenticated (PRNG encryption), as well as the SmartStart protocol for simplified network inclusion using a QR code. Since the device is not battery-powered, it also functions as a signal repeater within the Z-Wave mesh network.

🛠️ Discreet flush-mounted installation

Compact dimensions (42 × 37 × 18 mm) allow for mounting in a standard electrical box with a minimum depth of 60 mm. The safe low-voltage power supply (12 or 24 V DC) simplifies installation, which can be performed by a qualified technician without the need to modify the main electrical wiring.

The module has the following inputs and outputs

• 12/24VDC: + wire
• GND: - wire
• In1-4: control inputs (from switches, analog sensors,...)
• R: output for the red color of the LED strip, or 1st white LED strip
• G: output for the green color of the LED strip, or 2nd white LED strip
• B: output for the blue color of the LED strip, or 3rd white LED strip
• W: output for the white color of the LED strip, or 4th white LED strip

Specifications

🔖 Code: RGBW-CONTROL (formerly Fibaro RGBW Controller 2)

⚡ Input power supply: 12 - 24 V

🔌 Rated load current (resistive load only): 8 A at 240 V~ (6.5 A at 120 V~)

🌡️ Operating temperature (°C min/max): 0 - 35

📦 Installation in mounting boxes: Ø >= 50 mm, depth >= 60 mm

📡 Radio protocol: Z-Wave (500 series)

📶 Radio frequency (MHz): 868.4 or 869.8 (EU) / 908.4, 908.42 or 916.0 (US) / 921.4 or 919.8 (ANZ) / 869.0 (RU)

📍 Radio range (m): up to 40 m (depending on building structure)

📐 Dimensions (mm): 42.5 x 38.25 x 20.3

✅ Compliance with EU directives: RoHS 2011/65/EU - RED 2014/53/EU
