📱 Shelly Wall Display X2i (Silver): Your Command Center for Smart Home Control

The Shelly Wall Display X2i is an advanced, intelligent wall-mounted control panel that enables comfortable, centralized operation of your Shelly and third-party compatible devices (MQTT, Home Assistant) via a large, fully customizable 6.95-inch color touchscreen.

The display can be physically installed in either a landscape or portrait orientation, providing extraordinary flexibility to perfectly adapt to your room's layout and your personal visual preferences. You can freely arrange the home screen to suit your needs, adding key rooms, smart automations, or frequently used devices directly to the dashboard. This allows you to launch the desired action with a single quick tap the moment you enter the room.

Powerful Internals and a Built-In Relay

The Shelly X2i wall display is armed with modern Wi-Fi 6 and Bluetooth 5.0 technology, guaranteeing fast and extremely reliable wireless communication with your home router and the cloud. The central unit cleverly houses a replaceable power base directly inside its chassis, featuring one output with an integrated 5 A relay. This means the display also functions as a physical light switch, allowing direct hardwired control of the lighting circuit it is connected to in place of an old mechanical switch.

Powering the panel itself can be achieved either directly from a classic 100–240 V~ AC mains supply, or in a modern fashion via a USB-C cable. This significantly simplifies and speeds up installation in new builds and renovations where only low-voltage data cables might be present in the wall.

Built-In Sensors for Total Automation

The panel comes fully loaded with analytical sensors to deliver the most intuitive user experience possible:

• 👋 Proximity Sensor: Detects your physical presence. The screen automatically wakes up and illuminates before you even touch it.
• 🌞 LUX Sensor (Ambient Light): Automatically adjusts the screen’s backlight brightness so it won't blind you at night, or serves as a trigger for lighting automations in the room.
• 🔄 G-Sensor (Gyroscope): Automatically determines screen orientation (landscape / portrait) and handles gesture detection.

Rely on the agile quad-core processor and Android 11 operating system for lightning-fast reactions when toggling lights, tweaking system settings, or managing entire smart routines.

Excellent Integrations with Home Assistant and HVAC Systems

Connect the Shelly Wall Display X2i to the Shelly Smart Control app or directly to your Home Assistant server, and manage your smart home natively from one central point. Adjust your heating, ventilation, and air conditioning (HVAC) systems based on real-time temperature and humidity data received from other paired sensors across the house (such as the Shelly BLU H&T). The X2i wall display excels as a thermostat interface, providing you with intuitive, luxury-hotel-style climate control.

Additionally, link your Bluetooth speakers or the natively integrated Sonos audio system directly to the wall display to gain full audio control, stream music, set alarms, or broadcast audio greetings throughout your home system.

Key Communication Protocols

• 📶 Wi-Fi 6: Direct, ultra-fast connection over your local home network (2.4 GHz / 5 GHz dual-band).
• 🔗 Bluetooth 5.0: Fast local pairing and seamless communication with Shelly BLE sensors.
• 🖥️ Cloud-Free Local Control: The device fully supports MQTT, Webhooks, and HTTP RPC protocols, ensuring flawless, local-only integration with Home Assistant and other platforms.

Technical Parameters and Specifications

• 📱 Display Type: 6.95 inch, 5-point capacitive touchscreen
• 🖥️ Screen Resolution: 1440 × 720 px (HD quality)
• 🔊 Built-In Speaker and Microphone: Yes (0.8 W speaker) for audio notifications and feedback
• 📏 Dimensions with Power Base: 87 × 178 × 36 mm
• ⚖️ Weight with Power Base: 292 g
• 📦 Casing Material: Durable plastic, sleek aluminum frame, and tough front glass
• 🎨 Device Color: Elegant Silver
• 🔧 Mounting: Installation into a standard flush-mounted wall box (ideally horizontally or vertically)
• 🔌 Wire Cross-Section for Terminals: 0.75 – 2.5 mm²
• ⚡ Device Power Supply: 100 – 240 V~, 50/60 Hz OR via the USB-C port (5 V⎓, 1 A)
• 🔋 Standby Energy Consumption: < 5 W
• 🔌 Built-In Relay: Maximum switching current 5 A (at 240 V~)
• 🌡️ Operating Ambient Temperature: -20 °C up to +40 °C (intended for indoor use only)
• 📡 Built-In Sensors: Light sensor (LUX), Proximity sensor, G-sensor (Gyro)
• 💻 Processor and Memory: Rockchip RK3326-S, Quad-core Cortex-A35 1.5 GHz, 2 GB RAM, 8 GB Storage
• 📀 Operating System: Android 11
• 📅 OS Features: Up to 20 schedules, up to 20 webhooks simultaneously
